Single-Coil Boiler with Copper Tubes

• Fully compatible with condensing boilers, boilers, heat pumps, and solar energy systems

• High-comfort hot water supply ranging from 100 to 10,000 liters

• Maximum operating pressure (Tank): 10 bar

• Maximum operating pressure (Serpan): 16 bar

• Maximum operating temperature (Tank): 95°C

• Maximum operating temperature (Serpan n): 120°C

• Construction: S235JR steel

• Minimal scale formation thanks to its smooth surface. Superior-quality enamel coating compliant with DIN 4753-3 ensures hygienic hot water protection and optimal corrosion protection

• Magnesium anode protection

• High thermal insulation

• Installation-friendly design requiring minimal maintenance

• Corrosion protection with an external enamel coating

• Equipped with a sensor housing (1/2”) and a thermometer

• Recirculation connection option

• Insulation for 100–10,000 L: 18 kg/m³ soft 50 mm So foam

• Outer casing material for 100–10,000 L: Synthetic leather (Vinlex)

• Designed in accordance with TS 736 and TS EN 13445-3 standards
