Solid-Fuel Stoker-Fired Front-Fired Steam Boiler

Corrugated firebox, domed-mirrored Scottish steam boiler.

Perfectly compatible with the front-fired and side-fired steam boilers.

Combustion air fan and flue gas fan are fully automated with inverters.

Designed and manufactured in accordance with Lloyd’s Rules, DIN, and EN standards; optionally available with Lloyd’s and TÜV hydraulic test certificates.

The materials used in manufacturing are certified for origin and quality; the main steel components are manufactured from DIN 17155 material.

Our boiler tubes are seamless, high-pressure special boiler tubes made of drawn steel in accordance with DIN 17175 – 2448 standards.

The ISO 9001 quality management system, which forms the foundation of our quality system, has been adopted as the model for design/development, production, facility, and service quality management.

It is equipped with an environmentally friendly particulate filter made of silicone.

It is capable of burning liquid or gas fuel when a burner is mounted on it.

MECHANICAL COAL BURNER SPECIFICATIONS (STOKER)

It burns all types of lignite, pulverized coal (0.5–30 mm), and solid fuels such as walnut shells and apricot pits with high efficiency.

Since it ensures complete, smoke-free combustion, it brings the system up to operating conditions very quickly.

It is environmentally friendly, highly efficient, and very easy to operate.

It is manufactured to the desired capacity and can be easily installed on existing boilers.

It is the best solution for high-capacity applications where manual loading is difficult.

It eliminates human-caused combustion errors.

In steam boilers, its high performance makes it possible to reach the desired capacity.

In steam boilers, the system is controlled by a pressure switch; it stops when the steam pressure reaches the desired value and restarts when the pressure drops. This prevents fuel from being wasted.

The combustion chamber is water-circulated.

The system has few moving parts, reducing the likelihood of malfunctions.

The combustion chamber is manufactured from special high-temperature-resistant sheet metal.

The system’s installation and commissioning are performed by our expert teams.

MODULATION SYSTEM

In our system:

Steam pressure, pot temperature, pre-furnace temperature, inlet steam collector, and flue gas temperature are electronically controlled and can be continuously monitored digitally.

The components mentioned above are interconnected via a safety chain. This ensures that the risk of the boiler running dry is reduced to zero.

Additionally, our system includes alarm and interlock features.

All pumps, economizers, etc., operating in the system can be monitored via a diagram on the control panel. (This system has been highly praised by our customers as a state-of-the-art system.)

The combustion air and flue fan are inverter-controlled, allowing combustion to be fully controlled, with minimum, maximum, and nominal combustion levels provided fully automatically at the touch of a button.

This system is available exclusively at WENTA MAKİNA.

WENTA PREHEATER-EQUIPPED PRE-BURNER STEAM BOILER

A superb preheater and its equipment, specially designed by WENTA MAKİNA.

Specifically designed for BRICK COAL PLANTS, it continuously produces steam at 240°C, ensuring homogeneous production.

While the superheater draws steam at 240°C, steam at 170°C and 6 bar pressure is drawn from a separate collector for the molasses tank, roll press, etc., enabling the system to utilize steam at different pressures and temperatures.

This system has been well-received by our customers.

The superheated steam temperature remains constantly stable, providing exceptional ease of operation during production.
