A modular 3-busbar distribution unit, mountable on DIN rail or panel base, for power distribution from 160A to 250A in three-phase electrical panels.
TurkeyTurkey
| SKU (Stock Keeping Unit) | Feature | Description | Amperage | Input / Output | Input / Output Cable Ø | LxHxD (mm) | Product Price | Production Capacity |
|---|---|---|---|---|---|---|---|---|
| LB.3104.160 | 3 Busbar 125 -160A | 1+4 3P160 | 160 | 1 / 4 | 35 / 16 | 110 x 100 x 55 | ||
| LB.3209.160 | 3 Busbar 125 -160A | 4+6 3P160 | 160 | 4 / 6 | 35 / 16 | 160 x 100 x 55 | ||
| LB.3409.160 | 3 Busbar 125 -160A | 4+9 3P160 | 160 | 4 / 9 | 35 / 16 | 200 x 100 x 55 | ||
| LB.3416.160 | 3 Busbar 125 -160A | 6+12 3P160 | 160 | 6 / 12 | 35 / 16 | 245 x 100 x 55 | ||
| LB.3406.250 | 3 Busbar 160 -250A | 2+2+8 3P250 | 250 | 2 / 2+6 | 50 / 35+16 | 200 x 100 x 55 | ||
| LB.3409.250 | 3 Busbar 160 -250A | 4+9 3P250 | 250 | 2 / 2+9 | 50 / 35+16 |
| 245 x 100 x 55 |
| LB.3612.250 | 3 Busbar 160 -250A | 2+4+12 3P250 | 250 | 2 / 4+12 | 50 / 35+16 | 200 x 100 x 55 | 100000 |
